CVP1200.4D – Cerwin Vega – 4-Channel 1200W Bridgeable Class D Amplifier

R3435,00 Inc Vat.

SKU: CVP1200.4D Categories: , ,

Description

Latest High-Efficiency Class A/B Topology. Compact Size with Ambient backlit logo. RCA “Pass Thru” output for easy system expansion. Fully Variable Crossovers (12dB per octave). Handles HI and LO level input to 12V. 2 Ω Stable Stereo and 4Ω Mono (CH3/4) for 3 CH mode. Proprietary Vega Bass Boost EQ Up To 12dB.

Overview

CVP1200.4D – 4-Channel Bridgeable Class A/B Amplifier

Specifications

Cta-2006 Compliant
Number of Channels
1
Total Power (Sum of Rated Power)
1 Watts
Rated Power (RMS Continuous Power)
400 Watts x 1 @ 4Ω 800 Watts x 1 @ 2Ω 1200 Watts x 1 @ 1Ω
Dynamic Power (PVC/PowerCube®)
489 Watts x 1 @ 4Ω 889 Watts x 1 @ 2Ω 1389 Watts x 1 @ 1Ω
Bridgeable
No
Frequency Response
20 Hz – 250 Hz
Input Sensitivity
Low-Level: 150 mV – 4 V High-Level: 450 mV – 12 V
Circuit Topology Class
Class-D
Efficiency (average)
> 80%
Total Harmonic Distortion (THD+Noise)
4Ω: <1.0% 2Ω: <1.0% 1Ω: <1.0%
Signal Input
Low-Level: 2 RCA High-Level: 4-Pin Molex
Signal Output
Low-Level: 2 RCA (Pass-Thru active with RCA or Hi-Level input)
Tone Controls
0 to +18 dB @ 45 Hz
Crossover Controls
Low-Pass: 50 Hz – 250 Hz @ 12dB/Octave ButterworthInfrasonic: 15 Hz – 40 Hz @ 12dB/Octave Butterworth
Remote Controls
Yes
Visual Indicators
Power/Protect C.L.E.A.N. In C.L.E.A.N. Out
Power Wire Gauge
4 AWG
Power Input Connector
Compression Terminal Block
Speaker Wire Gauge
8 AWG
Speaker Output Connector
Compression Terminal Block
Cooling
Convection
Heatsink
Operating Voltage
9 – 16 VDC
Recommended Fuse (not included)
200 A
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
121 A
Dimensions (H x W x D)
(4.9 cm x 17.3 cm x 28.5 cm)

Owner's Manual

CVP1200.4D
